Epiroc SB 202 Hydraulic Breaker and Spare Parts
Epiroc SB 202 Hydraulic Breaker is a genuine original demolition attachment designed for efficient concrete breaking and rock demolition in construction and excavation projects. Perfect for 2-4 ton carriers, it delivers high impact energy with minimal vibration, ensuring operator comfort and extended tool life.
Built with 100% original Epiroc components, this breaker guarantees durable performance in tough working conditions. Its compact design provides precision and power for various demolition tasks. For reliable performance with authentic parts, contact us today for your Epiroc SB 202 needs!
Base plate of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3315295100 | 3315 295 100 – Base plate |
| 3315296490 | 3315 296 490 – Bolt kit |
| 0266211400 | 0266 211 400 – Hex nut |
Parts NO. |
Name |
| 3315299500 | 3315 299 500 – Hexagon screw |
| 3360430655 | 3360 430 655 – Open end spanner (24/27 mm) |
Service, repair and wear part kits of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3315294390 | 3315 294 390 – Label kit |
| 3382070079 | 3382 070 079 – Seal kit |
| 3315356200 | 3315 356 200 – Scraper ring |
| 0663210498 | 0663 210 498 – O-ring |
| 3115329002 | 3115 329 002 – Seal ring |
| 0663212000 | 0663 212 000 – O-ring |
0663211400 |
0663 211 400 – O-ring |
| 0664000003 | 0664 000 003 – Seal ring |
| 0663990036 | 0663 990 036 – Seal ring |
| 0663903201 | 0663 903 201 – O-ring |
| 3315336700 | 3315 336 700 – Plug |
| 0665909956 | 0665 909 956 – Wiper |
| 0665070130 | 0665 070 130 – Piston rod seal |
0663210494 |
0663 210 494 – O-ring |
| 0663211516 | 0663 211 516 – O-ring |
| 0665070129 | 0665 070 129 – Piston rod seal |
| 3315280800 | 3315 280 800 – Valve rubber |
| 0663211444 | 0663 211 444 – O-ring |
| 0663211400 | 0663 211 400 – O-ring |
Parts NO. |
Name |
| 0665090014 | 0665 090 014 – Seal ring |
| 3315352145 | 3315 352 145 – Lower hammer part kit |
| 3315354080 | 3315 354 080 – Bushing standard, complete |
| 3315356200 | 3315 356 200 – Scraper ring |
| 0663210498 | 0663 210 498 – O-ring |
| 3315277800 | 3315 277 800 – Stop ring |
3315135000 |
3315 135 000 – Lock pin |
| 3315134900 | 3315 134 900 – Retainer bar |
| 3315141900 | 3315 141 900 – Lock buffer |
| 3382070078 | 3382 070 078 – Accumulator repair kit |
| 3315359600 | 3315 359 600 – Coil spring |
| 3315359500 | 3315 359 500 – Diaphragm support |
| 3315289000 | 3315 289 000 – Diaphragm |
0211196534 |
0211 196 534 – Hex socket screw |
| 0686371805 | 0686 371 805 – Plug |
| 3115329002 | 3115 329 002 – Seal ring |
| 0663212000 | 0663 212 000 – O-ring |
| 3315366000 | 3315 366 000 – Valve |
| 0101414000 | 0101 414 000 – Pin |
Hydraulic breaker of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3315354080 | 3315 3540 80 – BUSHING STANDARD, complete |
| 3315356200 | 3315 3562 00 – SCRAPER RING |
| 0663210498 | 0663 2104 98 – O-RING |
| 3315277800 | 3315 2778 00 – STOP RING |
| 0686100009 | 0686 1000 09 – PLUG |
| 0686644207 | 0686 6442 07 – PLUG |
3315395200 |
3315 3952 00 – WATER NOSSLE |
| 3315135000 | 3315 1350 00 – LOCK PIN |
| 0108169127 | 0108 1691 27 – SPRING PIN, option |
| 3315134900 | 3315 1349 00 – RETAINER BAR |
| 3315141900 | 3315 1419 00 – LOCK BUFFER |
| 0686371803 | 0686 3718 03 – PLUG |
| 3315359600 | 3315 3596 00 – COIL SPRING |
3315359500 |
3315 3595 00 – DIAPHRAGM SUPPORT |
| 3315289000 | 3315 2890 00 – DIAPHRAGM |
| 3315282410 | 3315 2824 10 – ACCUMULATOR HOUSE |
| 0211196534 | 0211 1965 34 – HEX SOCK. SCREW |
| 0686371805 | 0686 3718 05 – PLUG |
| 3115329002 | 3115 3290 02 – SEAL RING |
| 0663212000 | 0663 2120 00 – O-RING |
3315366000 |
3315 3660 00 – VALVE |
| 0101414000 | 0101 4140 00 – PIN |
| 0663211400 | 0663 2114 00 – O-RING |
| 0580001846 | 0580 0018 46 – PIPE COUPLING |
| 0664000003 | 0664 0000 03 – SEAL RING |
| 3361353486 | 3361 3534 86 – CAP |
| 3360433774 | 3360 4337 74 – GREASE NIPPLE |
| 0663990036 | 0663 9900 36 – SEAL RING |
Parts NO. |
Name |
| 0686371801 | 0686 3718 01 – PLUG |
| 3315335000 | 3315 3350 00 – PRESSURE RELIEF VALVE, complete |
| 3315336700 | 3315 3367 00 – PLUG |
| 0665909956 | 0665 9099 56 – WIPER |
| 0665070130 | 0665 0701 30 – PISTON ROD SEAL |
| 0663210494 | 0663 2104 94 – O-RING |
0663211516 |
0663 2115 16 – O-RING |
| 3315277420 | 3315 2774 20 – LINER |
| 3315277300 | 3315 2773 00 – PISTON |
| 0665070129 | 0665 0701 29 – PISTON ROD SEAL |
| 3315293110 | 3315 2931 10 – BACK HEAD |
| 3315244881 | 3315 2448 81 – CHECK VALVE, complete |
| 3315280800 | 3315 2808 00 – VALVE RUBBER |
| 0147148103 | 0147 1481 03 – SCREW, HEX HEAD |
3315352020 |
3315 3520 20 – VALVE COVER |
| 0663211444 | 0663 2114 44 – O-RING |
| 3315277600 | 3315 2776 00 – CONTROL VALVE |
| 3315295100 | 3315 2951 00 – BASE PLATE |
| 3315296490 | 3315 2964 90 – BOLT KIT |
| 0211110349 | 0211 1103 49 – SCREW, M14 x 65 mm (2.56 in.) |
| 0665090014 | 0665 0900 14 – SEAL RING |
3315369460 |
3315 3694 60 – RESTRICTOR, complete |
| 0663210421 | 0663 2104 21 – O-RING |
| 3315369160 | 3315 3691 60 – RESTRICTOR, Ø 6.0 mm (Ø 0.24 in.) |
| 0663212141 | 0663 2121 41 – O-RING |
| 3315369200 | 3315 3692 00 – RESTRICTOR PLUG |
| 3315439145 | 3315 4391 45 – PROTECTIVE PLUG HATCON |
| 3315439101 | 3315 4391 01 – HATCON LABEL |
For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:
HATCON (Horizontal) of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3315439130 | 3315 4391 30 – DAMPER HATCON |
| 3315439110 | 3315 4391 10 – HOUSING TYPE 1 HATCON |
| 3315439140 | 3315 4391 40 – LOCK RING HATCON |
Parts NO. |
Name |
| 3315439120 | 3315 4391 20 – SLEEVE HATCON |
| 3315439100 | 3315 4391 00 – PRODUCT LABEL HATCON |
| 3315442600 | 3315 4426 00 – SCREW HATCON |
Bushing oversize, complete of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3315277990 | 3315 2779 90 – BUSHING OVERSIZE, complete |
| 3315282500 | 3315 2825 00 – SCRAPER RING |
Parts NO. |
Name |
| 0663210498 | 0663 2104 98 – O-RING |
Restrictor, complete of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3315369460 | 3315 3694 60 – RESTRICTOR, complete |
| 3315369200 | 3315 3692 00 – RESTRICTOR PLUG |
| 3315369160 | 3315 3691 60 – RESTRICTOR, Ø 6.0 mm (Ø 0.24 in.) |
| 0663212141 | 0663 2121 41 – O-RING |
Parts NO. |
Name |
| 0663210421 | 0663 2104 21 – O-RING |
| 3315369454 | 3315 3694 54 – RESTRICTOR, complete |
| 3315369450 | 3315 3694 50 – RESTRICTOR, complete (optional) |
| 3315369445 | 3315 3694 45 – RESTRICTOR, complete (optional) |
Optional equipment of Epiroc SB 202 Spare Parts
Parts NO. |
Name |
| 3360995717 | 3360 9957 17 – HYDRAULIC HOSE |
| 3362235159 | 3362 2351 59 – HYDRAULIC HOSE |
| 3363115426 | 3363 1154 26 – HYDRAULIC HOSE |
| 3363083313 | 3363 0833 13 – HYDRAULIC HOSE |
| 3363491002 | 3363 4910 02 – HYDRAULIC HOSE |
| 3363115423 | 3363 1154 23 – HYDRAULIC HOSE |
3363115424 |
3363 1154 24 – HYDRAULIC HOSE |
| 3363115425 | 3363 1154 25 – HYDRAULIC HOSE |
| 3363098018 | 3363 0980 18 – ADDITIONAL FITTING KIT 3363122354 |
| 3363122355 | 3363 1223 55 – BIO CHISEL PASTE CARTRIDGE FOR GREASE GUN, |
| 3363122357 | 3363 1223 57 – BIO CHISEL PASTE CONTAINER 15 kg (33 lbs) |
| 3363122358 | 3363 1223 58 – BIO CHISEL PASTE CONTAINER 45 kg (99 lbs) |
0909107100 |
0909 1071 00 – LUBRICAT.GUN |
| 3315353100 | 3315 3531 00 – BUSHING WEAR CONTROLLER |
| 3315383190 | 3315 3831 90 – CONTILUBE II MICRO |
| 3363094459 | 3363 0944 59 – NIPPLE, for charging the accumulator |
| 3360920415 | 3360 9204 15 – FILLING DEVICE, for accumulator |
| 3361329803 | 3361 3298 03 – FILLING HOSE, for charging the accumulator |
Parts NO. |
Name |
| 3315442500 | 3315 4425 00 – HATCON KIT 1 (3G) |
| 3315442520 | 3315 4425 20 – HATCON KIT 1 (LTE) |
| 3315439105 | 3315 4391 05 – SECURITY BIT HATCON |
| 3315439106 | 3315 4391 06 – MAGNET HATCON |
| 3083316206 | 3083 3162 06 – MOIL POINT |
| 3083316105 | 3083 3161 05 – CHISEL (cross) |
3083341105 |
3083 3411 05 – BLUNT TOOL |
| 3315370205 | 3315 3702 05 – SHAFT |
| 3083316300 | 3083 3163 00 – WIDE CHISEL |
| 3083316700 | 3083 3167 00 – WIDE CHISEL |
| 3083340946 | 3083 3409 46 – ASPHALT CUTTER |
| 3083340947 | 3083 3409 47 – ASPHALT CUTTER |
3315370900 |
3315 3709 00 – TAMPING PAD (square) |
| 3315371700 | 3315 3717 00 – POST DRIVER PAD (round) |
| 3315372300 | 3315 3723 00 – PILE DRIVER PAD (round) |
| 3315373000 | 3315 3730 00 – BUSHING PAD (round) |
| 3363120263 | 3363 1202 63 – MOIL POINT (X-Profile) |
| 3363120264 | 3363 1202 64 – CHISEL (X-profile) |
For details about our product offerings, pricing, or potential partnerships, our sales team is ready to provide comprehensive information:
